Mini Scissor Lift Table

Mini Scissor Lift Table

Lift tables can be applied in many work places to increase productivity and safety.

Load can be elevated or lowered to optimum heights at the push of a button.



*Small platform for special size material.

*High quality norm power pack from Europe for stable and safe lifting.

*Upper platform fitted with aluminium safety bar preventing descent on contact with obstructions

*Internal power pack euipped with relief valve against overloading and compensated flow valve for controlled lowering speed.

*Safety clearance between scissors to prevent trapping during operation

*Push button pedant control with up,down and emergency stop

*Meet EN1570 norm and ANSI/ASME safety standard.

Model NumberUM500UM1000
Capacitykg5001000
Lowered Heightmm162180
Raised Heightmm950770
Platorm Sizemm916×610916×610
Base Frame Sizemm700×450906×585
Lift Speedsec17-2215-20
Power Pack380V/50HZ,AC 0.75kw380V/50HZ,AC 1.1kw
Net Weightkg98115

    We will answer your email shortly!

    Lift Table AS

    Suitable for using in repairing, manufacture, wrapping, assembly line place, etc. New hydraulic system increases safety and protects your goods, stepless rate of lowering system remains irrespective of the weight of the load.

    Lift & Tilt Table

    The Lift &Tilt Tables are specifically designed to allow an operator to feed and unload parts from tote boxes or containers quickly and easily without lifting, bending, stretching, or reaching. Design with overload protection, safe and reliable.

    Spring Lift Table

    Self-leveling fully adjustable, weight sensitive. Designed to maintain an ideal working height for assembly lines and loading/unloading operations. Balance to achieved by double springs fitted to the shock absorbers. Simple to operate spring tension adjustment.
